Smart Flex AH31+
All season steer tyre for variable road conditions
M+S
3PMSF
Key features
- Regional Haul
Tractor/Trailer
Recommended
Hybrid segment tyres for multi-purpose application
-
Optimised tyre solution
Performance Test
Pattern Design
Adopted new technology and design provide increased safety with an economic advantage to the customer.
Pattern Design
Adopted new technology and design provide increased safety with an economic advantage to the customer.
-
Test Result
-
Spec
- 22.5”
-
295/80R22.5
- Fuel Efficiency C
- Wet Grip B
- External Rolling Noise 73
- Tube Type / Tubeless L
- Ply Rating 16
- Measuring Rim 9.0X22.5
- Load Index 154/149M
- Section Width(mm) 306
- Tread Width(mm) 250
- Tread Depth(mm) 16.5
- Static Loaded Radius(mm) 490
- Overall Diameter(mm) 1056
- M+S Y
- 3PMSF Y
- Origin Korea
-
295/80R22.5
- Fuel Efficiency C
- Wet Grip B
- External Rolling Noise 73
- Tube Type / Tubeless L
- Ply Rating 16
- Measuring Rim 9.00X22.5
- Load Index 154/149M
- Section Width(mm) 310
- Tread Width(mm) 250
- Tread Depth(mm) 16.5
- Static Loaded Radius(mm) 490
- Overall Diameter(mm) 1056
- M+S Y
- 3PMSF Y
- Origin China
- 22.5”
-
11R22.5
- Fuel Efficiency D
- Wet Grip B
- External Rolling Noise 72
- Tube Type / Tubeless L
- Ply Rating 16
- Measuring Rim 8.25X22.5
- Load Index 148/145L
- Section Width(mm) 280
- Tread Width(mm) 219
- Tread Depth(mm) 16.0
- Static Loaded Radius(mm) 492
- Overall Diameter(mm) 1057
- M+S Y
- 3PMSF Y
- Origin China
-
275/70R22.5
- Fuel Efficiency C
- Wet Grip C
- External Rolling Noise 73
- Tube Type / Tubeless L
- Ply Rating 16
- Measuring Rim 8.25X22.5
- Load Index 148/145M
- Section Width(mm) 275
- Tread Width(mm) 232
- Tread Depth(mm) 15.0
- Static Loaded Radius(mm) 447
- Overall Diameter(mm) 963
- M+S Y
- 3PMSF Y
- Origin China
-
275/70R22.5
- Fuel Efficiency C
- Wet Grip C
- External Rolling Noise 73
- Tube Type / Tubeless L
- Ply Rating 16
- Measuring Rim 8.25X22.5
- Load Index 148/145M
- Section Width(mm) 275
- Tread Width(mm) 232
- Tread Depth(mm) 15.0
- Static Loaded Radius(mm) 447
- Overall Diameter(mm) 963
- M+S Y
- 3PMSF Y
- Origin Korea
-
315/80R22.5
- Fuel Efficiency C
- Wet Grip B
- External Rolling Noise 73
- Tube Type / Tubeless L
- Ply Rating 20
- Measuring Rim 9.00X22.5
- Load Index 156/150L
- Section Width(mm) 320
- Tread Width(mm) 260
- Tread Depth(mm) 17.5
- Static Loaded Radius(mm) 501
- Overall Diameter(mm) 1084
- M+S Y
- 3PMSF Y
- Origin China
-
355/50R22.5
- Fuel Efficiency C
- Wet Grip B
- External Rolling Noise 69
- Tube Type / Tubeless L
- Ply Rating 18
- Measuring Rim 11.75X22.5
- Load Index 156K
- Section Width(mm) 355
- Tread Width(mm) 306
- Tread Depth(mm) 13.6
- Static Loaded Radius(mm) 431
- Overall Diameter(mm) 935
- M+S Y
- 3PMSF Y
- Origin Korea
-
385/55R22.5
- Fuel Efficiency C
- Wet Grip B
- External Rolling Noise 69
- Tube Type / Tubeless L
- Ply Rating 18
- Measuring Rim 12.25X22.5
- Load Index 160K
- Section Width(mm) 388
- Tread Width(mm) 320
- Tread Depth(mm) 15.0
- Static Loaded Radius(mm) 460
- Overall Diameter(mm) 1001
- M+S Y
- 3PMSF Y
- Origin China
-
385/65R22.5
- Fuel Efficiency C
- Wet Grip B
- External Rolling Noise 69
- Tube Type / Tubeless L
- Ply Rating 20
- Measuring Rim 11.75X22.5
- Load Index 160K
- Section Width(mm) 379
- Tread Width(mm) 308
- Tread Depth(mm) 15.5
- Static Loaded Radius(mm) 498
- Overall Diameter(mm) 1073
- M+S Y
- 3PMSF Y
- Origin China
