Smart Flex DH35

New all season tires designed for variable road conditions

M+S 3PMSF

Application
  • Urban
Truck Recommended
0Recently viewed products

Rib type tread pattern design and multi 3-Dimensional Sipes ensure low rolling resistance and excellent driving performance.

Hankook Tire & Technology-Tires-Smart-Smart Flex-DH35-Rib type tread pattern design and multi 3-Dimensional Sipes ensure low rolling resistance and excellent driving performance

Pattern design

Wide tread with 4 zigzag grooves

Wide tread with 4 zigzag grooves enables high mileage and excellent driving performance in variable conditions.

  • Conventional
  • Smartflex DH35

Multi 3-Dimensional Sipes

The special tread pattern design with multi 3-Dimensional Sipes offers low rolling resistance and outstanding traction.

Innovative rib type tread pattern design

Special tread pattern design for low rolling resistance and excellent traction performance across multi applications.

  • Semi groove rib
  • Block rib

Pattern design

  • TBR Technology

    Stiffness Control Contour Theory Technology(SCCT Technology)

    SCCT Technology is designed to reduce profile deformation. If the carcass profile is not kept constant, the internal force on the carcass will be concentrated on a specific point, belt edge or carcass turn up edge. In contrast, SCCT Technology controls the dispersion of internal force for better durability.

    Stiffness Control Contour Theory Technology(SCCT Technology)

    SCCT Technology is designed to reduce profile deformation. If the carcass profile is not kept constant, the internal force on the carcass will be concentrated on a specific point, belt edge or carcass turn up edge. In contrast, SCCT Technology controls the dispersion of internal force for better durability.

Test Result

Improved performance compared to predecessor tire

Mileage field test result

  • Spec

    • 205/75R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 66
      • Tube Type / Tubeless L
      • Ply Rating 12
      • Measuring Rim 6X17.5
      • Load Index 124/122M
      • Section Width(mm) 205
      • Tread Width(mm) 180
      • Tread Depth(mm) 13.1
      • Static Loaded Radius(mm) 354
      • Overall Diameter(mm) 758
      • M+S Y
      • 3PMSF Y
      • Origin China
    • 205/75R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 66
      • Tube Type / Tubeless L
      • Ply Rating 12
      • Measuring Rim 6X17.5
      • Load Index 124/122M
      • Section Width(mm) 207
      • Tread Width(mm) 180
      • Tread Depth(mm) 13.1
      • Static Loaded Radius(mm) 354
      • Overall Diameter(mm) 758
      • M+S Y
      • 3PMSF Y
      • Origin Korea
    • 215/75R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 66
      • Tube Type / Tubeless L
      • Ply Rating 12
      • Measuring Rim 6.00X17.5
      • Load Index 126/124M
      • Section Width(mm) 215
      • Tread Width(mm) 194
      • Tread Depth(mm) 13.0
      • Overall Diameter(mm) 775
      • M+S Y
      • 3PMSF Y
      • Origin Korea
      • OEM MAN/SCANIA, MBT
    • 215/75R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 66
      • Tube Type / Tubeless L
      • Ply Rating 12
      • Measuring Rim 6X17.5
      • Load Index 126/124M
      • Section Width(mm) 215
      • Tread Width(mm) 194
      • Tread Depth(mm) 13.0
      • Static Loaded Radius(mm) 359
      • Overall Diameter(mm) 775
      • M+S Y
      • 3PMSF Y
      • Origin China
    • 225/75R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 12
      • Measuring Rim 6.75X17.5
      • Load Index 129/127M
      • Section Width(mm) 228
      • Tread Width(mm) 200
      • Tread Depth(mm) 12.6
      • Static Loaded Radius(mm) 366
      • Overall Diameter(mm) 791
      • M+S Y
      • 3PMSF Y
      • Origin China
    • 225/75R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 12
      • Measuring Rim 6.75X17.5
      • Load Index 129/127M
      • Section Width(mm) 228
      • Tread Width(mm) 200
      • Tread Depth(mm) 12.6
      • Static Loaded Radius(mm) 366
      • Overall Diameter(mm) 791
      • M+S Y
      • 3PMSF Y
      • Origin Korea
    • 235/75R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 16
      • Measuring Rim 6.75X17.5
      • Load Index 132/130M
      • Section Width(mm) 238
      • Tread Width(mm) 220
      • Tread Depth(mm) 12.6
      • Static Loaded Radius(mm) 372
      • Overall Diameter(mm) 798
      • M+S Y
      • 3PMSF Y
      • Origin Korea
      • OEM MAN/SCANIA
    • 235/75R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 16
      • Measuring Rim 6.75X17.5
      • Load Index 132/130M
      • Section Width(mm) 238
      • Tread Width(mm) 220
      • Tread Depth(mm) 12.6
      • Static Loaded Radius(mm) 372
      • Overall Diameter(mm) 798
      • M+S Y
      • 3PMSF Y
      • Origin China
    • 245/70R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 14
      • Measuring Rim 7.5X17.5
      • Load Index 136/134M
      • Section Width(mm) 248
      • Tread Width(mm) 220
      • Tread Depth(mm) 12.6
      • Static Loaded Radius(mm) 372
      • Overall Diameter(mm) 798
      • M+S Y
      • 3PMSF Y
      • Origin China
    • 245/70R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 14
      • Measuring Rim 7.5X17.5
      • Load Index 136/134M
      • Section Width(mm) 248
      • Tread Width(mm) 220
      • Tread Depth(mm) 12.6
      • Static Loaded Radius(mm) 372
      • Overall Diameter(mm) 798
      • M+S Y
      • 3PMSF Y
      • Origin Korea
      • OEM MBT
    • 245/70R19.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 14
      • Measuring Rim 7.50X19.5
      • Load Index 136/134M
      • Section Width(mm) 252
      • Tread Width(mm) 224
      • Tread Depth(mm) 13.1
      • Overall Diameter(mm) 844
      • M+S Y
      • 3PMSF Y
      • Origin China
      • OEM Ford
    • 245/70R19.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 14
      • Measuring Rim 7.5x19.5
      • Load Index 136/134M
      • Section Width(mm) 252
      • Tread Width(mm) 224
      • Tread Depth(mm) 13.1
      • Static Loaded Radius(mm) 392
      • Overall Diameter(mm) 844
      • M+S Y
      • 3PMSF Y
      • Origin Korea
      • OEM MBT
    • 265/70R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 14
      • Measuring Rim 7.5X17.5
      • Load Index 140/138M
      • Section Width(mm) 262
      • Tread Width(mm) 236
      • Tread Depth(mm) 15.0
      • Static Loaded Radius(mm) 377
      • Overall Diameter(mm) 823
      • M+S Y
      • 3PMSF Y
      • Origin Korea
      • OEM MAN/SCANIA
    • 265/70R19.5
      • Fuel Efficiency X
      • Wet Grip X
      • External Rolling Noise X
      • Tube Type / Tubeless L
      • Ply Rating 18
      • Measuring Rim 7.5x19.5
      • Load Index 144/142J
      • Section Width(mm) 258
      • Tread Width(mm) 226
      • Tread Depth(mm) 15.0
      • Static Loaded Radius(mm) 405
      • Overall Diameter(mm) 874
      • M+S Y
      • 3PMSF Y
      • Origin Korea
    • 265/70R19.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 14
      • Measuring Rim 7.5x19.5
      • Load Index 140/138M
      • Section Width(mm) 260
      • Tread Width(mm) 236
      • Tread Depth(mm) 13.0
      • Static Loaded Radius(mm) 402
      • Overall Diameter(mm) 871
      • M+S Y
      • 3PMSF Y
      • Origin Korea
      • OEM MAN/SCANIA
    • 265/70R19.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 14
      • Measuring Rim 7.5X19.5
      • Load Index 140/138M
      • Section Width(mm) 260
      • Tread Width(mm) 236
      • Tread Depth(mm) 13.0
      • Static Loaded Radius(mm) 402
      • Overall Diameter(mm) 871
      • M+S Y
      • 3PMSF Y
      • Origin China
      • OEM Ford
    • 285/70R19.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 16
      • Measuring Rim 8.25X19.5
      • Load Index 146/144M
      • Section Width(mm) 282
      • Tread Width(mm) 246
      • Tread Depth(mm) 14.1
      • Static Loaded Radius(mm) 413
      • Overall Diameter(mm) 895
      • M+S Y
      • 3PMSF Y
      • Origin China
    • 285/70R19.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 16
      • Measuring Rim 8.25X19.5
      • Load Index 146/144M
      • Section Width(mm) 282
      • Tread Width(mm) 246
      • Tread Depth(mm) 14.1
      • Static Loaded Radius(mm) 413
      • Overall Diameter(mm) 895
      • M+S Y
      • 3PMSF Y
      • Origin Korea
      • OEM MAN/SCANIA, MBT
    • 305/70R19.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 16
      • Measuring Rim 9.0X19.5
      • Load Index 148/145M
      • Section Width(mm) 300
      • Tread Width(mm) 256
      • Tread Depth(mm) 15.5
      • Static Loaded Radius(mm) 427
      • Overall Diameter(mm) 924
      • M+S Y
      • 3PMSF Y
      • Origin Korea
    • 305/70R19.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 16
      • Measuring Rim 9X19.5
      • Load Index 148/145M
      • Section Width(mm) 300
      • Tread Width(mm) 256
      • Tread Depth(mm) 15.5
      • Static Loaded Radius(mm) 427
      • Overall Diameter(mm) 922
      • M+S Y
      • 3PMSF Y
      • Origin China
    • 8.5R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 12
      • Measuring Rim 6.00X17.5
      • Load Index 121/120L
      • Section Width(mm) 210
      • Tread Width(mm) 150
      • Tread Depth(mm) 13.6
      • Static Loaded Radius(mm) 375
      • Overall Diameter(mm) 807
      • M+S Y
      • 3PMSF Y
      • Origin China
    • 8.5R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 12
      • Measuring Rim 6.00X17.5
      • Load Index 121/120L
      • Section Width(mm) 211
      • Tread Width(mm) 150
      • Tread Depth(mm) 13.6
      • Static Loaded Radius(mm) 375
      • Overall Diameter(mm) 807
      • M+S Y
      • 3PMSF Y
      • Origin Korea
    • 8R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 10
      • Measuring Rim 6.00X17.5
      • Load Index 117/116L
      • Section Width(mm) 200
      • Tread Width(mm) 142
      • Tread Depth(mm) 12.0
      • Static Loaded Radius(mm) 365
      • Overall Diameter(mm) 782
      • M+S Y
      • 3PMSF Y
      • Origin Korea
    • 9.5R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 16
      • Measuring Rim 6.75X17.5
      • Load Index 129/127L
      • Section Width(mm) 236
      • Tread Width(mm) 178
      • Tread Depth(mm) 14.6
      • Static Loaded Radius(mm) 392
      • Overall Diameter(mm) 842
      • M+S Y
      • 3PMSF Y
      • Origin China
    • 9.5R17.5
      • Fuel Efficiency D
      • Wet Grip C
      • External Rolling Noise 73
      • Tube Type / Tubeless L
      • Ply Rating 16
      • Measuring Rim 6.75X17.5
      • Load Index 129/127L
      • Section Width(mm) 236
      • Tread Width(mm) 178
      • Tread Depth(mm) 14.6
      • Static Loaded Radius(mm) 392
      • Overall Diameter(mm) 842
      • M+S Y
      • 3PMSF Y
      • Origin Korea
